ABB DO86-48 Digital Output Board 58172367
- Brand: ABB
- Model Name: DO86-48
- Product Code (MPN): 58172367
- Series: MasterPiece 200 / Advant Controller 400 (AC400)
- Country of Origin: Finland
- Condition: New – Open Box
ABB DO86-48 Digital Output Board (Code: 58172367)
The ABB DO86-48 is a digital output board with a lot of density that is suited for tough industrial settings. It connects the central processing unit to field actuators like solenoids, motor starters, and pilot lights. It has 48 channels, which is one of the greatest densities in the Advant OCS family. This means that it may save a lot of room in the cabinet without losing electrical isolation or signal quality.
The most important thing for any good automation system is to find the correct balance between fast logic and long-lasting industrial strength. The ABB DO86-48 (Part Number 58172367) is a digital output module that has been carefully built for the MasterPiece 200 and Advant Controller 400 series. As an expert in industrial control systems, I can say that this module is still a key part of making old systems reliable. It has 48 independent output channels that can handle complex switching sequences with very little delay.
Technical Specifications
| Feature | Specification |
|---|---|
| Number of Channels | 48 Digital Outputs |
| Operating Voltage | 24V DC (Nominal) |
| Output Type | Transistor (Sourcing/Sink depending on wiring) |
| Max Current per Channel | 100 mA |
| Total Module Current | 4.8 A (Maximum) |
| Isolation | Optically Isolated from System Logic |
| Connection Type | Front-facing Connector Pins |
| Dimensions | Standard Advant Controller Board Size |
Features:
- High Channel Density: 48 channels fit in one slot, which gives your control cabinet the most I/O capacity possible.
- Strong Signal Isolation: Built-in optical isolation keeps the CPU safe from electrical surges and noise from the field.
- LED Diagnostics: The indicators on the front panel show the status of each output in real time, making it easier to fix problems and keep things running smoothly.
- Low Power Dissipation: Designed to be thermally efficient, so aggressive cabinet cooling isn’t needed as much.
- Plug-and-Play Compatibility: Works perfectly with ABB’s Advant Controller 410, 450, and MasterPiece 200 software.
Installation and Maintenance Guide:
- Thermal Management: Make sure your cabinet has enough airflow when you fully load all 48 channels at 100mA. The board works well, although high-density switching can cause localized heat.
- Surge Protection: When you switch inductive loads (solenoids/relays), always employ flyback diodes (snubbers). This stops back-EMF from wearing down the transistor outputs too soon.
- Check the connection: Make sure the front-end connectors are securely in place. Vibrations in factories can cause older connections to come loose over time, which can cause signals to drop out from time to time.
