The GE Fanuc IC695ETM001-EP Ethernet Interface Module is a rugged, high-performance module built exclusively for the PACSystems RX3i controller architecture. This module is designed for seamless industrial connectivity. It provides a connection between your PLC system and the broader Ethernet network to allow high-speed data transfer between other PACSystems equipment, Series 90 and VersaMax controllers.

This module delivers guaranteed connectivity via common TCP/IP stacks, whether you are working on complicated automation tasks or connecting legacy devices. Our in-house engineers have subjected this particular unit to thorough functional testing to ensure “Like-New” performance for your vital activities.

IC695ETM001-EP Series PACSystems RX3i Specifications

Applications

1. Manufacturing Automation: Connecting scattered control systems on the production floor.
2. Building Management: Integrating the HVAC and security control systems into a unified network.
3. Power Generation & Utilities: Reliable data capture, controller-to-controller communication.
4. Process Control Managing real-time data flow for complex industrial chemical or petrochemical operations.
5. Series 90 legacy controllers to PACSystems architecture infrastructure systems.

Compatibility:

Designed for use with the GE Fanuc/Emerson PACSystems RX3i backplane. Compatible with Series 90 and VersaMax controllers when configured via the Proficy Machine Edition software.

Engineer’s Guide:

1. Firmware Synchronization Before installation, check that the firmware version of your RX3i CPU is 2.51 or higher. This is necessary for safe “Hot Swap” capability.
2. Cable Integrity: Use a high-quality shielded twisted-pair (STP) Ethernet cable at all times. In noisy situations (e.g. engine rooms or huge industrial factories) EMI can be induced by unshielded cables, which results in occasional packet loss.
3. Station Manager Usage The Station Manager port should not be overlooked. It’s your best friend for low-level diagnostics if the primary network communication drops.
4. IP Conflict Prevention: When using the “Redundant IP” feature, confirm that your network switch supports the multicast/broadcast traffic required to prevent address conflicts.
5. Restart Mechanism: The recessed Ethernet Restart button is a lifesaver during commissioning—use it to cycle the module’s firmware without having to power-cycle the entire PLC rack.
