Mitsubishi Diesel Oil Purifier SJ10G Spares Lot – Comprehensive Maintenance Kit
The Mitsubishi Selfjector SJ10G is a corner stone of marine fluid engineering. It is used worldwide for the high efficiency centrifugal separation of fuel oils, diesel oils and lubricating oils on board boats. Continuous functioning is maintained through regular overhauls, which also help to prevent catastrophic bowl failures and assure optimum purification efficiency.
This is a premium, complete Mitsubishi Diesel Oil Purifier SJ10G Spares Lot. It combines important components across the whole separator system including the high speed bowl assembly, vertical shaft system, horizontal drive system, friction clutch and gear pump unit. The lot, specially curated for deep-sea vessels and engineering workshops, replaces worn elastomer profiles, damaged bearings, and exhausted mechanical springs with heavy-duty components engineered to survive intense centrifugal forces (G-forces) and high operational temperatures.
Model Details:
Compatible Equipment: Mitsubishi Selfjector (Centrifugal Oil Purifier)
Model Series: SJ10G (Gen-Series)
Lot Type: Critical Overhaul & Emergency Spares Bundle
Manufacturer Component Group: Multiple (Bowl, Shafts, Clutch, Frame, Pump)
Country of Origin: Japan
Parts Inventory Table and Specifications
| MPN / Part Number | Item Symbol / Position | Description | Material / Sub-Assembly | Qty Included |
|---|---|---|---|---|
| 455813001 | 118 | Main Seal Ring | High-Density Nitrile/Viton | 3 PCS |
| 436164001 | 520 | Flat Spring | Spring Steel | 1 PC |
| 337114001 | 705 | Operating Water Chamber | Vertical Shaft Assembly | 1 PC |
| 455814002 | 107 | O-Ring | Fluorocarbon / NBR | 6 PCS |
| H5004B2 | 707 | Tongued Washer | Hardened Steel | 8 PCS |
| 450524001 | 506 | Spring Retainer | Carbon Steel | 6 PCS |
| 450567001 | — | O-Ring Retainer | Machined Alloy | 4 PCS |
| 314254001 | 522 | Mist Cover | Vertical Shaft Assembly | 3 PCS |
| 521 | 521 | Spacer | Vertical Shaft Accessories | 1 PC |
| k2254511f | G03 | Oil Seal | Synthetic Rubber | 1 PC |
| k2204011F | G03 | Oil Seal (Viton) | Gear Pump Assembly | 1 PC |
| 205528102 | 111 | Disk | Stainless Steel (Bowl) | 1 PC |
| 37115001 | 703 | Operating Water Nozzle | Vertical Shaft Assembly | 1 PC |
| F1010030C | 612 | Bolt | High-Tensile Steel | 4 PCS |
| 337178001 | 322 | Impeller (1) | Frame & Cover Assembly | 1 PC |
| 200885001 | — | Bearing Housing | Vertical Shaft Assembly | 1 PC |
| 205527001 | — | Bowl Nut | High-Tensile Carbon Steel | 1 PC |
| F1004008B | 706 | Bolt | Steel | 4 PCS |
| 337177103 | 319 | Inlet Pipe | Frame & Cover Assembly | 1 PC |
| F1008020C | 626 | Bolt | Fastener | 2 PCS |
| 450525001 | — | Bearing Cap | Aluminum Alloy Casting | 1 PC |
| 461494001 | G27 | Bush (2a) | Bronze Casting (Gear Pump) | 1 PC |
| 200858001 | 601 | Horizontal Shaft | Forged Steel Assembly | 1 PC |
| E400404G7 | 628 | Socket Set Screw | Hardened Alloy | 1 PC |
| 456970001 | 57-1-3 | Orifice GP10G | Fluid Metering Component | 1 PC |
| 451277001 | 627 | Collar 2 (Motor Side) | Horizontal Shaft Assembly | 1 PC |
| 385078105 | 621 | Friction Block | Friction Clutch System | 9 PCS (Total) |
| 461495001 | G28 | Bush (2B) | Bronze Casting (Gear Pump) | 1 PC |
| C110040A2 | 603 | Key (10X8X40) | Carbon Steel (Horizontal) | 5 PCS |
| A10034A | 311 | O-Ring | Frame & Cover / General | 6 PCS (Total) |
| A20035A | 517 | O-Ring | Elastomeric | 1 PC |
| N0001011 | — | Elbow Connector | Brass / Steel Fitting | 3 PCS |
| A10024A | 315 | O-Ring | Sealing Element | 5 PCS |
| 337115001 | 703 | Operating Water Nozzle | Automatic Discharge System | 1 PC |
| A10032A | 220 / 211 | O-Ring | Sealing Profile | 5 PCS (Total) |
| L04403215 | 325 | Gasket | Premium Sealing Sheet | 6 PCS |
| 6206zzncx | 56 | Ball Bearing (NTN) | Double Shielded High-Speed | 1 PC |
| A20280A | 610 | O-Ring | NBR Sealing | 1 PC |
| E401012G7 | 620 | Socket Set Screw | Threaded Fastener | 1 PC |
| A10028A | 333 | O-Ring | Elastomeric | 1 PC |
| 436153001 | 535 | Spring Seat | Vertical Shaft Assembly | 1 PC |
| 351277001 | G10 | Drive Gear | Carbon Steel (Gear Pump) | 1 PC |
| A20080A | G02 | O-Ring (NBR) | Gear Pump Assembly | 2 PCS (Total) |
| 337108012 | 7 | Gravity Disc (79) | Stainless Steel (Bowl Accessory) | 6 PCS |
| A20155A | 505 | O-Ring | Specialized Interface | 1 PC |
| 200856001 | 622 | Bearing Housing (4) | Structural Housing | 1 PC |
| 337110001 | — | Disc Nut | Heavy Duty Carbon Steel | 1 PC |
| I27305J2 | 532 | Ball Bearing (3) (NTN) | High-Load Vertical Bearings | 1 PC |
| E400620G6 | 607 | Socket Set Screw | Locking Fastener | 1 PC |
| 337179001 | 321 | Impeller | Liquid Discharge Component | 1 PC |
| A10100A | 524 | O-Ring | Vertical Shaft Interface | 1 PC |
| 450079001 | G11 | Bush | Bronze Casting (Gear Pump) | 2 PCS |
| J2007C0 | 604 | Lock Nut | Horizontal Shaft Fastener | 1 PC |
| 436155001 | 711 | Packing | Molded Seal | 1 PC |
| E10051211 | 240 | Set Screw | Horizontal Shaft Assembly | 2 PCS |
| A90080A | 708 | O-Ring | High-Durability Compound | 4 PCS |
| 450428001 | 36-12-2 / 128 | Pilot Valve | Automatic Bowl Mechanism | 4 PCS (Total) |
| 455859001 | 102 | O-Ring | Static Seal | 1 PC |
| 459726001 | G22 | Safety Joint | Polyacetal (Gear Pump) | 2 PCS |
| 450481001 | 617 | Collar 1 (Motor Side) | Horizontal Drive Assembly | 1 PC |
| 317750001 | 125 (2A-6-3) | Valve Guide | Precision Control | 2 PCS |
| 0JDSP7017 | 0JDSPE003 | Coil | Diaphragm Assembly (Electrical) | 1 PC |
| A10011F | 126 (2a-5-3) | O-Ring | Specialized Sealing Nitrile | 8 PCS (Total) |
| D3035D2 | 606 | Retaining Ring (C) | Carbon Steel Wire | 1 PC |
| A41013F | 131 | O-Ring | Pressure Chamber Profile | 8 PCS |
| A20465A | 303 | O-Ring | Static Housing Profile | 1 PC |
| 45586001 | 117 | O-Ring | Bowl Distributing Ring Seal | 3 PCS |
| 456030001 | — | O-Ring Retainer | Retaining Ring Profile | 2 PCS |
| 436000001 | 130 | Valve Seat | Discharge Port Sealing | 4 PCS |
| A20140A | 624 | O-Ring (NBR) | Horizontal Shaft Assembly | 2 PCS |
| 368519001 | G19 | Valve Spring | Gear Pump Return Spring | 1 PC |
| A10031A | 323 | O-Ring | Interface Seal | 11 PCS |
| 411981001 | 508 | Upper Spring | Vertical Shaft Cushioning | 6 PCS |
| 455812001 | 133 | Packing | Compressed Flat Gasket | 5 PCS |
| A30070B | 114 | O-Ring | Dynamic Chamber Profile | 3 PCS |
| 456029001 | — | Joint | Mechanical Fitting | 1 PC |
| 450553001 | 104 | Drain Nozzle | Centrifugal Discharge Path | 4 PCS |
| A80243B | 116 | O-Ring | Heavy-Section O-Ring | 3 PCS |
| 42017F | 129 | O-Ring | Hydraulic Control Seal | 4 PCS |
| 450489001 | 132 | Valve Nut | Secure Mechanical Lock | 4 PCS |
| 10034A | 227 | O-Ring | General Casing Interface | 2 PCS |
Parts Applications
- 2500 & 5000-Hour Overhauls – Routine. Intended for planned preventative drydock or shipboard maintenance programs for the Mitsubishi SJ10G model series.
- HFO & MDO Separation Optimisation Restores the solid-sludge ejection dynamics when processing Marine Diesel Oil (MDO) and Heavy Fuel Oil (HFO) on commercial vessels, bulk carriers and container ships.
- Service for power plant & stationary separators: For industrial diesel power generation plants on land using Mitsubishi SJ-G series purifiers for lube oil reclamation.
- Emergency Emergency Breakdown Restoration: Offers quick availability of crucial keys, springs, impellers and high-wear O-rings to prevent operational oil loss or failure to open/close faults.
