Schneider Electric SmartX DO-FA-12 Module SXWDOA12X10001

Schneider Electric SmartX Controller DO-FA-12 I/O Expansion Module (SXWDOA12X10001)

The Schneider Electric SmartX Central I/O Module DO-FA-12 (MPN: SXWDOA12X10001) is a high-performance 12-channel digital output expansion module developed for the SpaceLogic/SmartStruxure AS-P Server environment. This module is designed for precision and easy scaling within the EcoStruxure Building Operation environment. It has 12 Form A relay digital outputs specifically tailored for direct load applications.

Its smart design includes a revolutionary two-piece plug-in architecture, so it can be installed hot-swappable and pre-wired for the entire site before attaching electronic modules. The DO-FA-12 removes the need for manual DIP switch configuration with its integrated auto-addressing, dramatically lowering commissioning time and reducing the risk of human mistakes in industrial and maritime automation deployments.

Main Features

• 12 Independent Form A Channels: High reliability digital relay outputs for direct load actuation and critical control loops
• Patented Two-Piece Sub-Base Design allows the installer to wire the entire central I/O terminal base before installing the electronic component, avoiding hardware damage during major building phases.
• Zero-Configuration Auto-Addressing: The modules automatically identify their position in the logical sequence order of the server chain, thus there is no need for manual DIP switch addressing or field commissioning button presses.
• Granular LED Diagnostics: Each of the 12 relay channels has its own dedicated green LED status indication, allowing field engineers to quickly diagnose visually.
• Improved Thermal Management: Designed with a protective cover for natural convection cooling, eliminating the need for failure-prone mechanical cooling fans.

Technical Specifications

Model Details

• Brand: Schneider Electric
• Short Code/Model Name: DO-FA-12 (Digital Output – Form A – 12 Channels)
• Global MPN / SKU: SXWDOA12X10001
• Alternative Cross-References: SXWDOA12X10001-EBO, SpaceLogic DO-FA-12, SmartStruxure DO-FA-12 Relay Module

Compatibility Architecture

• Server Compatibility: Explicitly engineered for integration alongside the SpaceLogic AS-P Server core computing unit.
• Required Base Hardware: Must be paired with the SpaceLogic Central I/O Terminal Base (MPN: SXWTBIOW110001) or compatible EcoStruxure Building Operation TB-IO-W1 terminal sub-bases.
• Software Environment: Fully supported by EcoStruxure Building Operation WorkStation software frameworks for custom as-built physical label generation and system diagnostic telemetry.
