Trio MC664-X P862-00593 Motion Controller

Trio MC664-X P862-00593 Flexaxis 8 Motion Controller

The Trio MC664-X P862-00593 is an ultra-high-performance, multi-axis Motion Coordinator designed for complex, high-speed industrial and marine automation architectures. Powered by a robust Quad-Core Cortex A9 1 GHz processor, this controller delivers microsecond-level synchronization across up to 128 total axes (64 hardware servo/stepper channels and 64 virtual axes). Built for demanding real-time environments, it features an integrated high-speed EtherCAT master port, dual Ethernet ports, CAN channels, and flexible expansion slot configurations via Trio’s Flexaxis bus. It provides precise 64-bit floating-point motion calculations, advanced multi-tasking TrioBASIC, and IEC 61131-3 PLC programming environments, making it ideal for multi-axis robotics, synchronized winches, dynamic positioning test rigs, and automated manufacturing machinery.

Model Details

• Manufacturer: Trio Motion Technology
• Series: MC664-X (Flexaxis / MC664X Architecture)
• Model Code: MC664-X
• Manufacturer Part Number (MPN): P862-00593
• Processor Architecture: Quad-Core ARM Cortex-A9 @ 1.0 GHz with dedicated communications core

Technical Specifications

Compatibility

• Compatible Expansion Modules: Trio Flexaxis digital/analog I/O modules, AXN axis modules, CANIO modules.
• Compatible Drives & Motors: EtherCAT-compatible servo drives (Yaskawa, Panasonic, Kollmorgen, Delta, Schneider, ABB) and stepper drives supporting CoE (CANopen over EtherCAT).
• Software Toolchain: Trio Motion Perfect v4 / v5 configuration and programming suite.

Key Features

1. Quad-core ARM Cortex-A9 processor executing deterministic multi-axis kinematic profiles with zero cycle lag.
2. High-speed native EtherCAT master interface supporting up to 64 synchronized nodes at sub-millisecond update rates.
3. 64-bit floating-point mathematical engine for high-precision camming, gearing, and linear/circular interpolation.
4. Flexible multi-tasking architecture allowing up to 32 concurrent TrioBASIC user programs plus PLC routines.
5. Robust onboard diagnostic LEDs for power, network traffic, CPU status, and individual axis error codes.

Applications

• Synchronized marine deck machinery, automated mooring winches, and dynamic positioning test stands.
• Multi-axis CNC cutting, routing, and high-speed gantry positioning systems.
• Packaging, bottling, and continuous web-handling converting machinery.
• Industrial robotics, pick-and-place arms, and flying shear synchronization lines.

Frequently Asked Questions

What is the primary difference between the standard MC664 and the MC664-X P862-00593 model?

The MC664-X features a powerful Quad-Core Cortex A9 1 GHz processor (designated by the P862 prefix), whereas standard baseline models utilize single-core configurations. This gives the MC664-X significantly higher processing bandwidth for heavy math-intensive kinematics and high-node EtherCAT configurations.

Can the MC664-X control third-party servo drives?

Yes. As long as the third-party servo drives support the EtherCAT (CoE – CANopen over EtherCAT) communication protocol, they can be seamlessly integrated and commanded directly via the controller’s master port.

How are expansion modules connected to the MC664-X controller?

Expansion modules attach directly to the side of the controller via Trio’s high-density backplane bus connector and secure locking earth screws that tie into the cabinet’s reference ground plane.

Is backward compatibility supported for programs written on older Trio motion controllers (such as the MC464)?

Yes. Legacy TrioBASIC programs can generally be migrated with minimal syntax adjustments, though execution speeds will be drastically improved due to the multicore architecture of the MC664-X.
